Fabric Laser Cutting Machine with Auto Feeding & CCD Visual Positioning
- Product details
-
Machine Features
1. Auto Feeding System：Dedicated auto feeder for fabric rolls, with auto calibration to ensure correct feeding path, making soft material processing more efficient.
2. CCD Visual Positioning：Optional wide-angle/small CCD camera for precise cutting of embroidery and printed fabric products, covering full table size.
3. Real-Time Parameter Adjustment：Machine speed and laser power output adjustable in real time, easy to operate for diverse processing needs.
4. Laser Power Compensation：Automatic laser power compensation function, significantly improving cutting effect and edge smoothness.
5. High Precision & Speed：Repeating positioning accuracy of ±0.01mm, engraving speed up to 1000mm/sec, meeting mass production demands.
6. Versatile Table & Compatibility：Blade table (honeycomb table optional), supports wood, acrylic, fabric, leather and 30+ materials for engraving/cutting.
7. Professional Control System：RuiDa DSP off-line control with RDworks/RDvision software, compatible with mainstream design formats (AutoCAD/CorelDraw).
8. Scalable Production：Suitable for large/medium enterprises (mass production) and small businesses/individual processors (custom orders).Machine Parameters
Product Model
KEY-1610
KEY-1810
KEY-1625
KEY-1825
Working Area 1600*1000mm 1800*1000mm 1600*2500mm 1800*2500mm Laser Power 100W/130W/150W 100W/130W/150W 130W/150W/180W 130W/150W/180W Laser type CO2 glass laser tube, wavelength 10.6μm, Water-cooled Engraving speed 0-1000mm/sec Cutting Speed 0-500mm/sec Repeating location ±0.01mm Transmission type Belt transmission Driving system Stepper motor Machine table Blade table (alternative: honeycomb table) Graphic format supported *.plt, *.dst, *.dxf, *.bmp, *.dwg, *.ai, *.las, supporting AutoCAD and CorelDraw Software supported CorelDraw, AutoCAD (support compatible) Control system RuiDa DSP Off-line control system, laser power 0~100% adjustable Minimum letter size Chinese 2.0×2.0mm, English 1.0×1.0mm Working voltage Single phase 220V/50Hz (Optional: 220V/60Hz, 110V/60Hz) Working condition 0-45℃; Humidity 5%-95% (no condensation) Machine Application
1. Textile & Garment Industry：Cuts cotton, linen, chemical fiber and leather for clothing, fabric accessories and textile raw material processing.
2. Home Textile Production：Processes sofa covers, curtain fabrics, carpets and customized home textile products with hollowing/cutting.
3. Outdoor Textile Products：Cuts outdoor tents, coated fabrics and tarpaulins with smooth edges and high durability.
4. Automotive Interior：Precision cutting of car interior soft materials, meeting automotive industry quality standards.
5. Customized Textile Processing：Supports personalized customization of various textile products, including small-batch hollowing and pattern cutting.
6. Multi-Material Processing：Beyond fabrics, engraves/cuts wood, acrylic, MDF, plastic and paper for advertising signs, craft gifts etc.Processed Sample
